Using Ruby On Rails With Apache2 On Debian Etch

Version 1.0
Author: Falko Timme

This article shows how you can install Ruby on Rails (RoR) and integrate it in Apache2 on a Debian Etch system (including a short section at the end showing how to use RoR in a web site created with ISPConfig). Ruby on Rails is a web application framework which is rapidly gaining popularity among web programmers. It aims to increase the speed and ease with which database-driven web sites can be created and offers skeleton code frameworks (scaffolding) from the outset. Applications using the RoR framework are developed using the Model-View-Controller design pattern.

This document comes without warranty of any kind! I want to say that this is not the only way of setting up such a system. There are many ways of achieving this goal but this is the way I take. I do not issue any guarantee that this will work for you!



1 Preliminary Note

I will use the hostname testapplication.example.com in this tutorial for the virtual host running Ruby on Rails.



2 Installing Ruby And Rails

In order to install Ruby and Ruby on Rails, we simply run

apt-get install ruby libzlib-ruby rdoc irb rubygems rails eruby



3 Installing Apache2 And mod-fcgid

Ruby on Rails can be integrated in Apache2 using mod-fcgid. Therefore we install the following packages:

apt-get install apache2 libapache2-mod-fcgid libfcgi-ruby1.8

Afterwards, we enable a few Apache modules:

a2enmod ssl
a2enmod rewrite
a2enmod suexec
a2enmod include

and reload Apache:

/etc/init.d/apache2 force-reload



4 Installing MySQL And The Ruby MySQL Bindings

Most probably you or your users will like to create database-driven Ruby on Rails applications, therefore we install the MySQL server and the Ruby MySQL bindings now:

apt-get install libmysql-ruby mysql-server

You should set a root password for MySQL now:

mysqladmin -u root password yourrootsqlpassword

If MySQL is listening not only on 127.0.0.1, but on other addresses as well (e.g. server1.example.com), you should set a root password for these addresses as well:

mysqladmin -h server1.example.com -u root password yourrootsqlpassword



5 Creating Our Ruby On Rails Environment

We can now create a directory in which we want to develop our future RoR applications. I'd like to develop them in /var/rails, so I create that directory now:

mkdir /var/rails

Apache2 should have read/write access to that directory, so we make the Apache user (www-data on Debian) and Apache group (again www-data) the owner and group of that directory:


6 Modifying Our Application's .htaccess File

The web folder of testapplication is /var/rails/testapplication/public. It contains an .htaccess file that we must modify so that Apache2 can run RoR applications using mod-fcgid.

vi /var/rails/testapplication/public/.htaccess

Comment out the AddHandler fastcgi-script .fcgi and AddHandler cgi-script .cgi lines and add the line AddHandler fcgid-script .fcgi. Also comment out the line RewriteRule ^(.*)$ dispatch.cgi [QSA,L] and add the line RewriteRule ^(.*)$ dispatch.fcgi [QSA,L] (note that it's now dispatch.fcgi instead of dispatch.cgi). Afterwards, the file should look like this:

# General Apache options
#AddHandler fastcgi-script .fcgi
#AddHandler cgi-script .cgi
AddHandler fcgid-script .fcgi
Options +FollowSymLinks +ExecCGI

# If you don't want Rails to look in certain directories,
# use the following rewrite rules so that Apache won't rewrite certain requests
#
# Example:
#   RewriteCond %{REQUEST_URI} ^/notrails.*
#   RewriteRule .* - [L]

# Redirect all requests not available on the filesystem to Rails
# By default the cgi dispatcher is used which is very slow
#
# For better performance replace the dispatcher with the fastcgi one
#
# Example:
#   RewriteRule ^(.*)$ dispatch.fcgi [QSA,L]
RewriteEngine On

# If your Rails application is accessed via an Alias directive,
# then you MUST also set the RewriteBase in this htaccess file.
#
# Example:
#   Alias /myrailsapp /path/to/myrailsapp/public
#   RewriteBase /myrailsapp

RewriteRule ^$ index.html [QSA]
RewriteRule ^([^.]+)$ $1.html [QSA]
RewriteCond %{REQUEST_FILENAME} !-f
#RewriteRule ^(.*)$ dispatch.cgi [QSA,L]
RewriteRule ^(.*)$ dispatch.fcgi [QSA,L]

# In case Rails experiences terminal errors
# Instead of displaying this message you can supply a file here which will be rendered instead
#
# Example:
#   ErrorDocument 500 /500.html

ErrorDocument 500 "<h2>Application error</h2>Rails application failed to start properly"



7 Creating A Virtual Host For Our RoR Application

(If you use ISPConfig, please go to chapter 8!)

Now it's time to create an Apache vhost for our application. I will use the hostname testapplication.example.com so that our application can be reached under http://testapplication.example.com (assuming that testapplication.example.com points to the correct IP address).

The easiest way to create such a vhost is to replace the existing default vhost in /etc/apache2/sites-available/default (assuming that this default vhost isn't needed!):

cp /etc/apache2/sites-available/default /etc/apache2/sites-available/default_old
cat /dev/null > /etc/apache2/sites-available/default
vi /etc/apache2/sites-available/default
<Virtualhost *:80>
   ServerName testapplication.example.com
   DocumentRoot /var/rails/testapplication/public/

   <Directory /var/rails/testapplication/public>
      Options ExecCGI FollowSymLinks
      AllowOverride all
      Order allow,deny
      Allow from all
   </Directory>
</Virtualhost>

Of course, instead of replacing the default vhost, you can simply add your testapplication.example.com vhost at the end of /etc/apache2/sites-available/default so that you keep the default vhost.

Now we restart Apache:

/etc/init.d/apache2 restart

Next we open http://testapplication.example.com in a browser. We should see the default RoR page:

That's it! Now we can start to develop our RoR application in the /var/rails/testapplication directory.



8 RoR And ISPConfig

(If you don't use ISPConfig, skip this chapter!)

In this chapter I assume that you have created a web site called testapplication.example.com with the document root /var/www/web1/web in ISPConfig, and that your RoR testapplication is still in /var/rails/testapplication.

To make our RoR testapplication available in the testapplication.example.com vhost which we have created in ISPConfig, we do the following:

First, we put the following lines into the Apache Directives field of the testapplication.example.com web site in ISPConfig:

<Directory /var/www/web1/web>
  Options +ExecCGI +FollowSymLinks
  AllowOverride all
</Directory>

Then we rename /var/rails/testapplication/public to /var/rails/testapplication/web, copy the contents of /var/rails/testapplication to /var/www/web1, and make the Apache user the owner of /var/www/web1/web:

cd /var/rails/testapplication
mv public web
cp -pfr * /var/www/web1
chown www-data:web1 /var/www/web1/web

That's it. The RoR application should now work in the testapplication.example.com vhost which we have created in ISPConfig.
